Build

Three calls and a grant. If a machine can sign, it can meter, spend and be checked.

NODE 20+
MIT
v0.4 · MAINNET

A swordsmith's forge at night, woodblock — PLATE II
Nothing here is generated for you.The key was already in the machine.

Install

NO ACCOUNT · NO KEY TO PASTE

There is no signup step, because there is nothing to sign you up for. The SDK talks to the secure element already sitting in the machine.

npmnpm i @katana/sdk
pnpmpnpm add @katana/sdk
bunbun add @katana/sdk

Attach the machine

Bind the SDK to the key already in the secure element. Nothing is generated, nothing is stored.

import { attach } from "@katana/sdk";

const machine = await attach({
  did: "did:katana:p256:KL-0117",
  // the key never leaves the die; the SDK only asks it to sign
  signer: secureElement(),
});

await machine.attest();   // -> { ok: true, chain: "verified" }

Take a grant

Scope, ceiling, expiry. The grant is the only authority the machine has, and it dies on its own.

const grant = await machine.grant({
  scope: ["arm.lift", "arm.place"],
  ceiling: { wh: 8_000, currency: "usd", max: 4.0 },
  expiry: "+45m",
});

grant.on("revoked", () => machine.park());

Meter and settle

Open against a dock, let it tick, close. The channel nets off-chain and clears in one transaction.

const session = await grant.open({ dock: "dock-01" });

for await (const tick of session.meter()) {
  // { wh, ts, sig } — at most one second apart
  telemetry.push(tick);
}

await session.close();    // -> settled, sub-cent

Or declare it

NO JS UNTIL YOU TRULY NEED IT

For the common case there is no imperative code at all — the same four rails, expressed as attributes.

html

<katana-machine
  did="did:katana:p256:KL-0117"
  scope="arm.lift arm.place"
  ceiling="8kWh"
  expiry="45m"
  dock="dock-01"
></katana-machine>

What comes back

PROOF BESIDE THE RESULT

Every call returns the proof beside the result. Keep it or drop it — the ledger kept its own copy either way.

json

{
  "session": "sx_01J8Y…",
  "total_wh": 3417,
  "amount":   { "usd": 0.4521 },
  "ticks":    412,
  "settled":  { "tx": "0x9c1f…", "at": 1782413071 },
  "proof": {
    "machine": "did:katana:p256:KL-0117",
    "dock":    "did:katana:p256:dock-01",
    "grant":   "gr_01J8Y…",
    "sig":     "cose:…"
  }
}

When it refuses

THE FOUR YOU WILL ACTUALLY SEE

CodeMeaningWhat to do

E_ATTESTSignature did not verifyThe key answered but the chain did not. Usually a maker root that has moved on.

E_SCOPECall outside the grantThe actuator is not named in scope. Widen it at issue — never at the call site.

E_CEILINGMeter reached the ceilingExpected, not exceptional. Close the session and open a new grant.

E_EXPIREDGrant diedTime-boxed authority did exactly its job. There is nothing here to recover.

Events

FOUR YOU CAN SUBSCRIBE TO

EventPayloadWhen

meter.tick{ wh, ts, sig }At most one second apart, for as long as a session is open.

grant.revoked{ grant_id, by, at }Fires before the next actuator call is refused, not after.

session.settled{ total_wh, amount, tx }The channel closed. This is the receipt.

machine.parked{ reason }Your own handler ran. Nothing about this touched the chain.

Everything here runson mainnet today.There is no waitlist.

Read the spec
